High-Temperature And Corrosion-Resistant Electrically Heated Reaction Vessel Series Equipment

Brand Name : Chenglong

Model Number : DFG Series

Place of Origin : China

MOQ : 1 unit

Price : Consultation

Supply Ability : 50,00pcs/Month

Packaging Details : Wooden box packaging or as per customer requirements

Characteristics : Automatic control

Application : The chemical pigment industry, etc

Color : Green

Name : Electric heating reactor series

Product brand : Cheng Long

Advantages : High-temperature resistant and corrosion-resistant

Contact Now

Product Description

Electric heating reaction vessel equipment
The series of reaction vessels are widely used in the pharmaceutical, building materials, chemical pigment, resin and food industries. They feature rapid heating, high-temperature resistance, corrosion resistance, automatic control and automatic temperature rise.

High-Temperature And Corrosion-Resistant Electrically Heated Reaction Vessel Series Equipment

Users can place orders for production based on the working medium, heating method, annual production capacity and technical requirements.

High-Temperature And Corrosion-Resistant Electrically Heated Reaction Vessel Series Equipment

Main technical specifications and parameters

Model Nominal capacity(L) Actual capacity(L) Heater power Oil jacket capacity(L) Inner pot dimension(mm) Jacket dimension(mm) Outside dimension(mm) Electric motor power(KW) Weight(Kg)
DFG50 50 78 4x2kw 96 Φ400 Φ600 Φ824x2015 1.1 270
DFG100 100 127 6x2kw 127 Φ500 Φ700 Φ1004x2120 1.1 340
DFG300 300 327 6x4kw 218 Φ700 Φ900 Φ1208x2495 2.2 700
DFG500 500 509 9x4kw 269 Φ900 Φ1100 Φ1468x2695 2.2 930
DFG1000 1000 1017 12x4kw 400 Φ1200 Φ1400 Φ1896x3110 4 1610
DFG2000 2000 2244 12x5kw 750 Φ1400 Φ1600 Φ2265x3610 4 1850
DFG3000 3000 3360 15x6kw 854 Φ1600 Φ1800 Φ2560x4120 5.5 2700
DFG5000 5000 5390 15x6kw 925 Φ1800 Φ2000 Φ2750x4520 11 3950

Note: Please specify your usage requirements when placing an order. We can design and manufacture according to your requirements
